SPACE GASS
SPACE GASS is a multi-purpose 3D analysis and design program for structural engineers. Its extensive range of features make it suitable for anything from beams, trusses and frames to buildings, towers, tanks, cable structures and bridges. Capabilities include a 64-bit multi-core solver, silky smooth 3D rendered graphics, plate finite elements, frame elements, cable elements, tension/compression-only elements, moving loads and links to many CAD and building management programs.
Why SPACE GASS
Save time, money, and get a safe and efficient design.
Silky smooth graphical interface that lets you see your changes visually as you go.
A fast sparse matrix solver that fully utilizes the parallel processing power of multi-core computers.
A wide range of structural modeling tools, analysis options and design modules.
Comprehensive video tutorials to walk you through some of the tricky stuff.
Configurable for stand-alone or floating network systems.
Learn more
Altair S-FRAME
With S-FRAME, users can model, analyze, and design any structure regardless of its geometric complexity, material type, loading conditions, nonlinear effects, or design code requirements. S-FRAME’s automated framework generators build models quickly and import models with BIM and DXF import links, and users can maximize productivity with integrated concrete and steel design tools for design, optimization, code compliance, and report generation. With S-FRAME, users can quickly define structures using modeling automation to generate regular framework structures, and standard or custom trusses, and use clone tools to replicate all or part of the model. Additionally, users can save modeling time by importing existing BIM and DXF models. S-FRAME’s advanced meshing tools create the finite element mesh, giving users the power to generate detailed analysis results in their specific areas of interest. Users can explore those areas of interest by easily converting members to multi-shell models.
Learn more
AxisVM
The primary applications of AxisVM are in the design of buildings, and industrial and geotechnical structures. Due to its powerful finite element solver and practical modeling tools, it has also been used in bridge design, and in the design of composite structures, machines, and vehicles. Besides the basic configurations, optional design modules are available for structures made of reinforced concrete, steel, timber, and masonry members and connections. In addition, thanks to the special elements and analysis capabilities, users have successfully applied AxisVM to the design of innovative and custom structures. Reports can be created based on tables, drawings, and detailed design calculations with additional headings and text lines. Reports are auto-updating, i.e. generated based on the most current model data and results.
Learn more
Altair SimSolid
By performing structural analyses on fully featured CAD assemblies within minutes, SimSolid is the game-changing simulation technology for designers, engineers, and analysts. It eliminates geometry preparation and meshing: the two most time-consuming, expertise-extensive and error-prone tasks performed in a conventional structural simulation.
Multiple design scenarios can be simulated quickly under real-life conditions. Early CAD models, in any common format, can be used. SimSolid tolerance of imprecise geometry means that, unlike CAD-embedded simulation tools, there is no need to simplify complex geometries before analyzing designs.
SimSolid supports all typical connections (bolt/nut, bonded, welds, rivets, sliding) and analysis of linear static, modal, thermal properties, along with more complex coupled, nonlinear, transient dynamic effects.
Learn more
