OrCAD® X is a unified PCB design software platform that offers significant improvements in ease of use, performance, automation, data management, and collaboration. Our cloud-enabled product suite contains applications for schematic, simulation, and PCB layout. OrCAD X Capture is one of the most widely used schematic design solutions for the creation and documentation of electrical circuits. PSpice® is our virtual SPICE simulation environment integrated within Capture that allows you to prototype your designs using the industry-leading, native analog, mixed-signal, and advanced analysis engines to deliver a complete circuit simulation and verification solution. Our two PCB layout environments, OrCAD X PCB Editor and OrCAD X Presto, allow designers to easily collaborate between ECAD/MCAD teams and build better PCBs faster. OrCAD X Presto is a new user-friendly option offering a simpler interface for quick-turn PCB design.

MPLAB® Mindi™ Analog Simulator reduces circuit design time and design risk by simulating analog circuits prior to hardware prototyping. The simulation tool uses a SIMetrix/SIMPLIS simulation environment, with options to use SPICE or piecewise linear modeling, that can cover a very wide set of possible simulation needs. This capable simulation interface is paired with proprietary model files from Microchip to model specific Microchip analog components in addition to generic circuit devices. This simulation tool installs and runs locally on your PC. Once downloaded, no Internet connection is required, and the simulation run time is not dependent on a remotely located server. The result is fast, accurate analog circuit simulations. Run the simulation tool directly on your own PC; once installed no Internet connection is required.
